VWS-770-FF-DC

Printer Friendly
Available
VWS-770-FF-DC
VWS-770-FF-DC VWS-770-FF-DC VWS-770-FF-DC VWS-770-FF-DC VWS-770-FF-DC VWS-770-FF-DC VWS-770-FF-DC VWS-770-FF-DC

Steel Stacker with Fixed DC Powered Winch 770 Lb. Capacity Black / Yellow

The electric winch stacker features a heavy duty mast and a DC winch for easier and safer lifting. Lift and lower by DC winch and steel cable mechanism. A full height push-handle is included for easy steering and excellent visibility through welded mesh guard. The unit rolls smoothly on two rigid and two swivel wheels with brakes for easy maneuvering.

  • Fixed forks for constant width
  • Ergonomic handle for full posture transferring
  • DC operated for constant power supply
  • (2) 12V batteries
Assembled Wt.(lbs.): 350 Assembled Size: 26.75"W x 48.875"L x 78"H

Total Ship Wt.(lbs.): 462 (only 1 package) Package 1 Size: 40"W x 48"D x 81"H Color: Black / Yellow Non-Returnable

Uniform Capacity (lb.): 770 Service Range (in.): 3-3/8 to 59 Fork Length (in.): 30
Fork Width (in.): 4 Fixed Straddle Leg Spacing (in.): 26-3/4 (OD) Fixed Fork Spacing (in.): 26-3/4 (OD)
Operation: DC Winch Lift Motor: DC 12V / 120 W - Single Phase Battery: (2) 12V / 30 Ah
Battery Charger: 24V / 8 Ah Amperage: 10 Charger Type: 3 Prong
Continuous Runtime: 2-3 hours Intermittent Runtime: 5-6 Hours Horizontal Load Center (in.): 24
Horsepower: 0.5 Rear Caster Quantity/Diameter/Width (in.): (2) 6 x 1-1/2 Rear Caster Material: Polyurethane
Front Caster Quantity/Diameter/Width (in.): (2) 3 x 1-1/2 Front Caster Material: Polyurethane Overall Mast Height (in.): 78

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: VWS-770-FF-DC
Available
VWS-770-FF-DC

Steel Stacker with Fixed DC Powered Winch 770 Lb. Capacity Black / Yellow

The electric winch stacker features a heavy duty mast and a DC winch for easier and safer lifting. Lift and lower by DC winch and steel cable mechanism. A full height push-handle is included for easy steering and excellent visibility through welded mesh guard. The unit rolls smoothly on two rigid and two swivel wheels with brakes for easy maneuvering.

  • Fixed forks for constant width
  • Ergonomic handle for full posture transferring
  • DC operated for constant power supply
  • (2) 12V batteries
Dimensions: 26.75"W x 48.875"L x 78"H Sell UOM: -- Color: Black / Yellow
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 462 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (lb.): 770 Service Range (in.): 3-3/8 to 59 Fork Length (in.): 30
Fork Width (in.): 4 Fixed Straddle Leg Spacing (in.): 26-3/4 (OD) Fixed Fork Spacing (in.): 26-3/4 (OD)
Operation: DC Winch Lift Motor: DC 12V / 120 W - Single Phase Battery: (2) 12V / 30 Ah
Battery Charger: 24V / 8 Ah Amperage: 10 Charger Type: 3 Prong
Continuous Runtime: 2-3 hours Intermittent Runtime: 5-6 Hours Horizontal Load Center (in.): 24
Horsepower: 0.5 Rear Caster Quantity/Diameter/Width (in.): (2) 6 x 1-1/2 Rear Caster Material: Polyurethane
Front Caster Quantity/Diameter/Width (in.): (2) 3 x 1-1/2 Front Caster Material: Polyurethane Overall Mast Height (in.): 78
