VWS-770-AA-DC

Printer Friendly
Available
VWS-770-AA-DC
VWS-770-AA-DC VWS-770-AA-DC VWS-770-AA-DC VWS-770-AA-DC VWS-770-AA-DC VWS-770-AA-DC VWS-770-AA-DC

Steel Stacker with Adjustable DC Powered Winch 770 Lb. Capacity Black / Yellow

The electric winch stacker features a heavy duty mast and a DC winch for easier and safer lifting. Lift and lower by DC winch and steel cable mechanism. A full height push-handle is included for easy steering and excellent visibility through welded mesh guard. The unit rolls smoothly on two rigid and two swivel wheels with brakes for easy maneuvering.

  • Adjustable forks for full grasp
  • Ergonomic handle for full posture transferring
  • DC operated for constant power supply
  • (2) 12V batteries
Assembled Wt.(lbs.): 492 Assembled Size: 45"W x 48"L x 78"H

Total Ship Wt.(lbs.): 566 (only 1 package) Package 1 Size: 45"W x 64"D x 85"H Color: Black / Yellow

Uniform Capacity (lb.): 770 Service Range (in.): 1-9/16 to 63 Fork Length (in.): 30
Fork Width (in.): 3-1/8 Leg Width (in.): 2-3/8 Adjustable Straddle Leg Spacing (in.): 40-1/8 to 50 (ID)
Adjustable Fork Spacing (in.): 6-1/4 to 19-11/16 (OD) Operation: DC Winch Lift Motor: DC 12V / 120 W
Battery Quantity/Volts: (2) 12V / 40-60 Ah Battery Charger: 12V / 8 Ah Lifting Speed w/ Load (sec.): 3.35
Lifting Speed w/o Load (sec.): 4.34 Rear Caster Quantity/Diameter/Width (in.): (2) 6 x 1-1/2 Rear Caster Material: Phenolic
Front Caster Quantity/Diameter/Width (in.): (2) 4 x 1-1/2 Front Caster Material: Phenolic Horizontal Load Center (in.): 24

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: VWS-770-AA-DC
Available
VWS-770-AA-DC

Steel Stacker with Adjustable DC Powered Winch 770 Lb. Capacity Black / Yellow

The electric winch stacker features a heavy duty mast and a DC winch for easier and safer lifting. Lift and lower by DC winch and steel cable mechanism. A full height push-handle is included for easy steering and excellent visibility through welded mesh guard. The unit rolls smoothly on two rigid and two swivel wheels with brakes for easy maneuvering.

  • Adjustable forks for full grasp
  • Ergonomic handle for full posture transferring
  • DC operated for constant power supply
  • (2) 12V batteries
Dimensions: 45"W x 48"L x 78"H Sell UOM: -- Color: Black / Yellow
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 566 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (lb.): 770 Service Range (in.): 1-9/16 to 63 Fork Length (in.): 30
Fork Width (in.): 3-1/8 Leg Width (in.): 2-3/8 Adjustable Straddle Leg Spacing (in.): 40-1/8 to 50 (ID)
Adjustable Fork Spacing (in.): 6-1/4 to 19-11/16 (OD) Operation: DC Winch Lift Motor: DC 12V / 120 W
Battery Quantity/Volts: (2) 12V / 40-60 Ah Battery Charger: 12V / 8 Ah Lifting Speed w/ Load (sec.): 3.35
Lifting Speed w/o Load (sec.): 4.34 Rear Caster Quantity/Diameter/Width (in.): (2) 6 x 1-1/2 Rear Caster Material: Phenolic
Front Caster Quantity/Diameter/Width (in.): (2) 4 x 1-1/2 Front Caster Material: Phenolic Horizontal Load Center (in.): 24
