SNM15-62-FF-27

Printer Friendly
Available
SNM15-62-FF-27
SNM15-62-FF-27 SNM15-62-FF-27 SNM15-62-FF-27 SNM15-62-FF-27

Steel Narrow Mast Stacker DC Powered 62 In. Raised Height Fixed Fork 27 In. Fork Width 1,500 Lb. Capacity Black / Yellow

The narrow mast stacker is great for the shipping and manufacturing facilities. The stacker provides a fast efficient solution to loading and unloading products in closely confined areas. The stacker features a simple throttle design for lifting control, as well as, infinite forward and reverse speed adjustments. The unit drives on poly on steel steering and load wheels, which provide excellent maneuverability. A battery charger, gauge and horn are included. Models are available with fixed or adjustable forks as well as fixed or adjustable leg supports.

  • Emergency reverse belly switch instantly reverses direction
  • Stacker is an efficient solution to loading and unloading in closely confined areas
  • Throttle design lifts and controls speed adjustments for ideal operation and optimal results
  • Includes poly-on-steel wheels for excellent maneuverability and fixed forks for maximum efficiency
Assembled Wt.(lbs.): 768 Assembled Size: 28"W x 66"L x 77.25"H

Total Ship Wt.(lbs.): 772 (only 1 package) Package 1 Size: 60"W x 75"D x 84"H Color: Black / Yellow Non-Returnable

Uniform Capacity (lb.): 1,500 Service Range (in.): 2 to 62 Fork Width/Length (in.): 5-9/10 x 42-1/8
Fixed Fork Spacing (in.): 26-3/4 Overall Mast Height (in.): 78 Drive Motor: DC 24V / 0.4 KW
Lift Motor: DC 24V / 2.0 KW Battery: (2) 12V / 80 Ah Battery Charger: 24V / 8 amp
Operation Time with Constant Use (hrs.): 3 to 4 Operation Time with Intermittent Use (hrs.): 8 Turning Radius (in.): 88-5/8
Travel Speed - Loaded (MPH): 1.24 Travel Speed - Unloaded (MPH): 1.86

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: SNM15-62-FF-27
Available
SNM15-62-FF-27

Steel Narrow Mast Stacker DC Powered 62 In. Raised Height Fixed Fork 27 In. Fork Width 1,500 Lb. Capacity Black / Yellow

The narrow mast stacker is great for the shipping and manufacturing facilities. The stacker provides a fast efficient solution to loading and unloading products in closely confined areas. The stacker features a simple throttle design for lifting control, as well as, infinite forward and reverse speed adjustments. The unit drives on poly on steel steering and load wheels, which provide excellent maneuverability. A battery charger, gauge and horn are included. Models are available with fixed or adjustable forks as well as fixed or adjustable leg supports.

  • Emergency reverse belly switch instantly reverses direction
  • Stacker is an efficient solution to loading and unloading in closely confined areas
  • Throttle design lifts and controls speed adjustments for ideal operation and optimal results
  • Includes poly-on-steel wheels for excellent maneuverability and fixed forks for maximum efficiency
Dimensions: 28"W x 66"L x 77.25"H Sell UOM: -- Color: Black / Yellow
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 772 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (lb.): 1,500 Service Range (in.): 2 to 62 Fork Width/Length (in.): 5-9/10 x 42-1/8
Fixed Fork Spacing (in.): 26-3/4 Overall Mast Height (in.): 78 Drive Motor: DC 24V / 0.4 KW
Lift Motor: DC 24V / 2.0 KW Battery: (2) 12V / 80 Ah Battery Charger: 24V / 8 amp
Operation Time with Constant Use (hrs.): 3 to 4 Operation Time with Intermittent Use (hrs.): 8 Turning Radius (in.): 88-5/8
Travel Speed - Loaded (MPH): 1.24 Travel Speed - Unloaded (MPH): 1.86
