Model Details

← All Products- ← Ergonomic Solutions- ← Stackers -← Narrow Mast Stackers with Powered Lift- SLNM-118-FF

SLNM-118-FF

Printer Friendly
Available
SLNM-118-FF
SLNM-118-FF SLNM-118-FF SLNM-118-FF SLNM-118-FF

Steel Narrow Mast Stacker DC Powered 118 In. Raised Height Fixed Forks 45-1/4 In. Fork Length 1,500 Lb. Capacity Yellow

The narrow mast stacker is great for the shipping and manufacturing facilities. The stacker provides a fast efficient solution to loading and unloading products in closely confined areas. The unit features a simple push button design for lifting control, nylon steering and load wheels for excellent maneuverability, and a battery charger and gauge. Models are available with fixed or adjustable forks as well as fixed or adjustable leg supports.

  • Narrow mast stacker is ideal for shipping and manufacturing facilities
  • Stacker is an efficient solution to loading and unloading in closely confined areas
  • Push-button design lifts and controls speed adjustments for ideal operation and optimal results
  • Includes nylon wheels for excellent maneuverability and fixed forks for maximum efficiency
Assembled Wt.(lbs.): 690 Assembled Size: 29"W x 66.5"L x 78"H

Total Ship Wt.(lbs.): 756 (only 1 package) Package 1 Size: 41"W x 65"D x 88"H Color: Black Non-Returnable

Uniform Capacity 0 - 63" (lb.): 1,500 Uniform Capacity 63 - 118" (lb.): 1,000 Service Range (in.): 3-1/4 to 118
Fork Width/Length (in.): 5-9/10 x 45-1/4 Fixed Fork Spacing (in.): 26-3/4 (OD) Overall Mast Height (in.): 77-3/4
Lift Motor: DC 12V / 1.3 KW Battery Charger: 12V / 6 amp Raise Time w/ Load: 5.9" / sec
Raise Time w/o Load: 2.95" / sec Lower Time w/ Load: 4" / sec Lower Time w/o Load: 3.15" / sec

Quickship Item?


NOT A Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: SLNM-118-FF
Available
SLNM-118-FF

Steel Narrow Mast Stacker DC Powered 118 In. Raised Height Fixed Forks 45-1/4 In. Fork Length 1,500 Lb. Capacity Yellow

The narrow mast stacker is great for the shipping and manufacturing facilities. The stacker provides a fast efficient solution to loading and unloading products in closely confined areas. The unit features a simple push button design for lifting control, nylon steering and load wheels for excellent maneuverability, and a battery charger and gauge. Models are available with fixed or adjustable forks as well as fixed or adjustable leg supports.

  • Narrow mast stacker is ideal for shipping and manufacturing facilities
  • Stacker is an efficient solution to loading and unloading in closely confined areas
  • Push-button design lifts and controls speed adjustments for ideal operation and optimal results
  • Includes nylon wheels for excellent maneuverability and fixed forks for maximum efficiency
Dimensions: 29"W x 66.5"L x 78"H Sell UOM: -- Color: Black
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 756 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity 0 - 63" (lb.): 1,500 Uniform Capacity 63 - 118" (lb.): 1,000 Service Range (in.): 3-1/4 to 118
Fork Width/Length (in.): 5-9/10 x 45-1/4 Fixed Fork Spacing (in.): 26-3/4 (OD) Overall Mast Height (in.): 77-3/4
Lift Motor: DC 12V / 1.3 KW Battery Charger: 12V / 6 amp Raise Time w/ Load: 5.9" / sec
Raise Time w/o Load: 2.95" / sec Lower Time w/ Load: 4" / sec Lower Time w/o Load: 3.15" / sec
